MRT1000 Personal radiation survey meter

  • Measuring range: Dose equivalent rate: 0.01 mu Sv/h ~ 1 MSV/h; The cumulative
  • Resolution Accuracy: 0.01μSv/h
  • Communication storage: Real-time display; Cumulative dose
  • Working time: About 1000h
  • Main unit weight: 85g
  • Dimensions: 70 * 40 * 95 (mm)
  • Package dimensions: 14*9.5*5.8cm
  • Total weight: 150g

Product Overview

MRT1000 is a high accurate personal dosimeter which is used to monitor X-rays and γ rays. The device adopts the energy compensated GM counter tube as detector, with high sensitivity and accuracy. Equips powerful microprocessor and high-end OLED displays, making the operation easier. It has a strong anti-interference ability and can do any combination of sound, flash and vibration three types of alarm modes, the alarm threshold can be set freely, when reaching the alarm threshold, it will alarm and remind the staff to pay attention to safety. The main technical parameters are in accordance with nation and international standards, it is more powerful in function, portable and power consumption in similar products.

Function & application

  • Real-time measurement of dose rate and simultaneously record the cumulative dose
  • The dose rate alarm threshold and the dose alarm thresholds can be set freely
  • Any combination of three types of alarm modes (sound, flash and vibration) can meet various alarm needs
  • A dual alarm functions of the dose rate and dose
  • Build-in memory to prevent the value of the cumulative dose, the dose rate alarm threshold and the dose alarm thresholds data from losing when power down
  • Continuous monitoring of battery power, with low battery prompt
  • Chinese/ English menu switch freely
  • Humanized design, easy to operate
  • Support wireless personal dose management system(wireless version only)

Working Principle

Energy compensated GM counter tube, the tube change ray into impulse signal, then show the value.

Working Conditions

  • Working Temperature: -10℃~+50℃≤±10%
  • Working Humidity: 0~95%RH (+35℃)≤±10%

Instrument Features

  1. Battery level indicator
  2. Device run heartbeat indicator
  3. Rate,dose rate alarm indicator(only flashes when the dose rate alarm)
  4. Dose,dose alarm indicator(only flashes when the dose alarm)
  5. Real-time detection value
  6. Unit

Please visit the Mitech website for more information.
